Hallbach Array

Industry: Science & Technology

A European Research establishment contacted us to design a dipole Halbach Array to produce a 1 Tesla field in the centre of the Halbach Array.

We have 3D FEA software (Infolytica Magnet) to assist with the magnetic design on such things as Halbach Arrays. In this case we had to design the unit to give a 1 Tesla field in the centre and to demonstrate the magnetic field profile within the central cylinder air gap (flux map).

We then used our in-house magnet design and manufacturing facilities to produce the Halbach Array at low cost while maintaining the high quality required for the application.

We can design Halbach Arrays of varying lengths, diameters, field strengths, magnetic patterns, etc.

Find out more about Bespoke Magnets or contact us for more details.
